Quick Details
Application: PE Pipe
Plastic Processed: HDPE LDPE ABS PMMA
Screw Design: Single-screw
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Sansu-PE pipe extrusion line
Voltage: 380V/50HZ, 415V/50HZ, 440V/50HZ, 220V/50HZ
Certification: CE ISO BV
diameter:: 16-800mm
inverter:: ABB
warranty: 12 months after installation in customer’s factory
Packaging & Delivery
Packaging Details plastic film or plywood
Delivery Time 35 working days
HDPE PIPE PRODUCTION LINE
PE pipe producing line, equipped with different extruding dies and necessary auxiliary machines, can make various PE pipes.
Features of this line:
1. high efficiency single screw extruder: high rotating speed, good compounding effect and stable extrusion ensuring big capacity.
2. extruding die: adopting latest designed die head with spiral distributing flow channel, built-in temperature controlling device which make the extrusion more evenly.
3. vacuum calibrating tank: advanced water loop vacuum calibration, two vacuum chambers ensuring perfect roundness of the pipe, multi-section 6meter water spraying tank, make sure cooling the pipe thoroughly, the main body of the tank made of stainless steel.
4. haul-off machines: 2 laws, 3 claws, 4 claws, 6 claws and 8 claws are provided to manufacture various pipes, haul-off speed governed by the FUJI or ABB inverter.
5. cutting unit: dust-free cutting, with PLC controlling and meter counter.
6. stacking unit: providing pipe winder or pipe stacker.
7. controlling system: supply manual controlling cabinet and SIEMENS PLC touch screen controlling.
Main technical parameter
|
Item |
SJGF75 |
SJGF160 |
SJGF250 |
SJGF450 |
SJGF630 |
SJGF800 |
SJGF1000 |
SJGF1200 |
SJGF1600 |
|
Diameter |
20-75 |
63-160 |
75-250 |
160-450 |
315-450 |
400-800 |
500-1000 |
630-1200 |
1000-1600 |
|
Main machine |
SJ25/25 |
SJ25/25 |
SJ25/25 |
SJ25/25 |
SJ25/25 |
SJ150/33 |
SJ150/33 |
SJ90/33 |
SJ120/33 |
|
Max. capacity |
120-150 |
120-300 |
280-400 |
500-700 |
700-900 |
900-1200 |
900-1200 |
900-1400 |
1000-1700 |
|
Total power |
110 |
130 |
260 |
400 |
500 |
600 |
600 |
900 |
1000 |
Application:
1. Urban tap water pipe network system
Large diameter PE pipe, health non-toxic, not fouling, more suitable for urban water supply main conduit and buried tube, safety, hygiene, convenient construction.
2. Agriculture irrigation pipe
PE pipe inside sleek, great flow, cross road construction, good impact resistance, it is the ideal tool for agricultural irrigation.
3. Industrial materials duct
Chemical industry, chemical fiber, food, forestry, pharmacy, light industry and papermaking, metallurgical and other industrial raw material conveying pipe.
4.Landscaping water supply network
Landscaping need lots of water pipe, PE pipe toughness and low cost, make it become the best choice.
5.Sewage discharge pipes
PE pipe have unique corrosion resistance, can be used in industrial wastewater, sewage discharged pipe, low costs and maintenance costs
